F15BML
F15BMS

Item

F15BML
F15BMS
F15BWL
F15BWS
F15FWL F15FWL
Overall length
mm(in.)
1001(39.4)
643(25.3)
Overall width
mm(in.)
427(16.8)
369(14.5)
Overall height
mm(in.)
1207(47.5)
1080(42.5)
1207(47.5)
1080(42.5)
1207(47.5)
1080(42.5)
Transom height
mm(in.)
508(20.0)
381(15)
508(20.0)
381(15)
508(20.0)
381(15)
Weight
kg
51
49
53
51
53
51
Full throttle operating range
r/min
4500-5500
Maximum output

KW(HP)

11(15)@5000r/min
Idling speed(Neutral)
r/min
900-1000
Engine type
OHC
Cylinders
L2
Displacement
cm3
323
Bore x Stroke
mm(in.)
59.0x59.0(232x2.32)
Ignition system
CDI
Control system
Tiller control
Remote control
Starting system
Manual start
Manual start/Electric start
Gear positions
Forward-Neutral-Reverse
Gear ratio
2.08(27/13)
Trim and tilt system
Manual tilt
Fuel tank capacity
L
24L
Maximum fuel consumption
L/h
5.3
Engine oil capacity
L
1.0
Gear oil capacity
cm3
250
Propeller options
in
3-9 1/4 " x 11 " or 3- 9 1/4 x 8"



*Propeller choice will vary by boat size and application.
*B=Back control F=Front control M=Manual start
